PANASONIC WV-BF320 CCTV Camera
PANASONIC WV-BF320 CCTV Camera
The Panasonic WV-BF320 is designed to look like a smoke detector. It features a 1/4" interline transfer CCD with digital signal processing. PRODUCT FEATURES• Unobtrusive smoke detector housing design• High resolution, black-and-white image in lighting as low as 0.5 lux (0.05fc)• 380 lines resolution• 46dB S/N ratio, with AGF off WV-BF320 Covert Black-andWhite Camera in Smoke Detector-Style Housing GENERAL SPECIFICATIONS Type 1/4" interline transfer CCD with DSP in a smoke detector-style housing TV System Black-and-white Image Area 3.61(H)mm x 2.72(V)mm Scanning Frequency Horizontal: 15.734kHz Vertical: 59.94Hz Frames Per Second 30 frames Sync Internal Horizontal Resolution 380 lines Minimum Illumination 0.5 lux (0.05fc) S/N Ratio 46dB (with AGF off) Electronic Light Control On AGC On Terminals DC input connector, video output Power Source 12VDC with supplied AC adaptor Humidity 90% Dimensions 113 ⁄16"H x 51 ⁄16"D (46 x 129mm)
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Model | cctv |
| Surveillance Technology | CCTV |
| Brand | Panasonic |
The Panasonic WV-BF320 is designed to look like a smoke detector. It features a 1/4″ interline transfer CCD with digital signal processing. PRODUCT FEATURES• Unobtrusive smoke detector housing design• High resolution, black-and-white image in lighting as low as 0.5 lux (0.05fc)• 380 lines resolution• 46dB S/N ratio, with AGF off WV-BF320 Covert Black-andWhite Camera in Smoke Detector-Style Housing GENERAL SPECIFICATIONS Type 1/4″ interline transfer CCD with DSP in a smoke detector-style housing TV System Black-and-white Image Area 3.61(H)mm x 2.72(V)mm Scanning Frequency Horizontal: 15.734kHz Vertical: 59.94Hz Frames Per Second 30 frames Sync Internal Horizontal Resolution 380 lines Minimum Illumination 0.5 lux (0.05fc) S/N Ratio 46dB (with AGF off) Electronic Light Control On AGC On Terminals DC input connector, video output Power Source 12VDC with supplied AC adaptor Humidity 90% Dimensions 113 ⁄16″H x 51 ⁄16″D (46 x 129mm)
