KT&C OMNI EZ HD-TVI 1080p Box Camera CVBS analog out, 2.8-12 MP lens, DUAL power
KT&C OMNI EZ HD-TVI 1080p Box Camera CVBS analog out, 2.8-12 MP lens, DUAL power
KEZ-c2RICS KT&C OMNI EZ HD-TVI Camera 2 MP HD 1080p Box camera with OSD control 2.8-12mm Megapixel Lens INCLUDED Listed Price is MAP (minimum advertised price) enforced by KT&C. Please contact us for our special price! * The stock image(s) are for illustration purpose. Actual item may look different. 1080p HD Over Regular Coax or UTP True Day/Night Box Camera D-WDR, OSD with UTC, Dual Voltage Superlative HD resolution of 1080p Full HD or 720p HD for amazing image quality and useful digital zoom on live view and playback - Field select 1080p or 720p - Field select 30/25 FPS Operation over ‘almost any’ wire - More than 1000 feet on standard RG59 coax - More than 1500 feet on RG6 - More than 500 feet on UTP (one pair from a Cat5e cable, using optional KA-HDBAL passive balun pair). HD-TVI HD BNC main output CVBS analog service video output on rear - Use standard hand held test monitors - Convenient aim and focus; ease of service 1/2.8” Sony progressive scan CMOS sensor with .07 lux native light sensitivity Flexible choice of Megapixel lens focal length to capture the desired field of view Supports both manual or DC iris lenses True Day/Night low light operation plus Digital Slow Shutter low light enhancement (More than 2~4X DSS should be limited to select applications.) Simple and easy to use OSD setup menu - Local 5-button menu control on rear cover - Up-the-cable control from OMNI EZHD recorders (or other compatible Coaxitron® control equipment) - Digital Wide Dynamic Range to handle the most challenging of bright or unbalanced lighting conditions - Programmable Back Light Compensation (BLC) and High Light Compensation (HLC) - Adjustable 3D Noise Reduction to increase low light picture clarity and conserve DVR HDD disk space - Privacy masking for 8 configurable zones - Lens shading compensation for even exposure out to the lens periphery - Defog improves image contrast in the presence of haze or smoke that obscures image details - Image H/V flip and rotate, digital zoom and more Dual voltage 24VAC/12VDC operation with low current draw Choice of black or silver housing (2 models) to blend or contrast with the décor Standard ¼-20 attachment points top and bottom for mounting flexibility in our out of a an optional protective housing HD-TVI cameras require HD-TVI compatible DVR systems Imaging Device 1/2.8” Sony 2.1Mp Progressive Scan CMOS Video Format Main Output : 1080p30/25, 720p/30/25 HD-TVI (OSD selectable) Secondary Output : CVBS (OSD selectable NTSC/PAL) service video test point Actual/Effective Picture Elements 2000 (H) x 1121 (V) / 1984 (H) x 1105 (V) Maximum Video Output Resolution 1920 (H) x 1080 (V) / 1080p @ 30/25 Sensitivity .1 lux color, .07 lux B/W (F=1.0) Day/Night Type Digital Day/Night Lens Type CS Type [C-mount with included adapter] DC iris support Video Output Connector Type TVI and CVBS : BNC 75Ω Sync. Mode Internal OSD Menu Multiple functions using 5 button controls on rear of housing; UTC Control OSD Languages English, Spanish, Portuguese, German, Russian, Japanese, French UTC Control Full OSD Menu access via up-the-cable (Coaxitron® type ) signaling DWDR / BLC / HLC OFF/WDR/BLC/HLC Selectable Adjustable for Level 1~10; also BLC area, HLC color. Auto Gain Control OFF; 2~42dB Electronic Shutter Auto; FLK; or Manual 1/30 (25) to 1/30,000 White Balance Auto / Push Lock / Auto EXT / Manual Color Correction Gamma 0.45~.65, adjustable Day & Night True D/N with motorized IR cut filter Optional color-only and B/W only modes under OSD control Digital Slow Shutter (DSS) DSS low light boost Off/Auto 2X~16X* *DSS levels above 4X should be used only after careful consideration of scene dynamics 3D-DNR Off/Low/Mid/High Digital Zoom 1X~8X Defog Off/Low/Mid/High Mirror Off / H-flip, V-flip, HV flip (rotate) Motion Detection Off/On for programmable zone with sensitivity adjust (pixel change detection) Privacy Mask Off/On with full programmability for 8 selectable zones Lens Shading Compensation Off/Low/Mid/High DPC (Defective Pixel Correction) Off/On Other OSD Functions Camera Title with position; Image Sharpness Power Source 12VDC/24VAC Power Consumption 12VDC:240mA / 24VAC:3.4W max. Operating Temperature 14°F~122°F ; -10°C~50°C Storage Temperature -4°F~140°F ; -20°C~60°C Humidity Less than 80% non-condensing Dimensions 2.28” x 2.28” x 4.77” / 58mm x 58mm x 121.4mm (includes BNC at rear) Weight 0.485 lb / 220g Certifications CE / FCC Warranty 3 years We welcome ALL Wholesale orders: Please contact us for special discounts on quantity / bulk orders. We also have special price for resellers and installers !! For any questions or inquiries, please contact ebay ID: esscctv Shipping Terms Item normally gets shipped out within 24 hours. Item will be normally shipped via UPS Ground, but we reserve the right to ship smaller items with USPS (either by First Class Mail or Priority Mail). All UPS shipments require a physical address International shipping is available. Please note all of our analog cameras are in NTSC format If provided, FREE shipping applies to continental US states only. ESS CCTV is not responsible for all customs, taxes, and duties occuring on international orders Warranty and Returns Most of the ESS CCTV items are covered by 1 year manufacturer warranty. The warrany only covers failure due to defects in material and workmanship by the manufacturer. The warranty does not cover damage due to everyday usage You may return merchandise purchased from ESS CCTV for a refund or a replacement. All product returns requires a RMA (return merchandise authorization) number. The RMA number should be written on your returning pacakge. Please contact us to issue your RMA number All returned items for a refund/credit should be in its original, "resalable" condition. You may not be responsible for a refund or credit otherwise. ESS CCTV follows ebay's 14 days return policy. Items should be returned within 14 days from the order date to receive a refund. Items should be returned within 30 days from the received date for an exchange, replacement, or a store credit. Buyers are responsible for the shipping cost on all returns except for DOA (dead on arrival) products. 15% restocking fee is applied to any non-defective returns for a refund. . If your package is damaged upon arrival, please refuse the the delivery and contact us immediately. All shipping-related claims should be made within 3 calendar days after the date of receipt. Accessories and Expendables will not be covered under the warranty nor accepted for exchange or returns Contact us ebay ID: esscctv Monday to Friday 10:00 AM ~ 5:00 PM PST
Specifications
| Restocking Fee | 15% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Type | Box/Body |
| Color Mode | Color Day, B&W Night |
| Brand | KT&C USA |
| Model | KEZ-c2RICS-2812 |
| Features | Infrared/Night Vision |
| MPN | Does Not Apply |
KEZ-c2RICS KT&C OMNI EZ HD-TVI Camera 2 MP HD 1080p Box camera with OSD control 2.8-12mm Megapixel Lens INCLUDED Listed Price is MAP (minimum advertised price) enforced by KT&C. Please contact us for our special price! * The stock image(s) are for illustration purpose. Actual item may look different. 1080p HD Over Regular Coax or UTP True Day/Night Box Camera D-WDR, OSD with UTC, Dual Voltage Superlative HD resolution of 1080p Full HD or 720p HD for amazing image quality and useful digital zoom on live view and playback – Field select 1080p or 720p – Field select 30/25 FPS Operation over ‘almost any’ wire – More than 1000 feet on standard RG59 coax – More than 1500 feet on RG6 – More than 500 feet on UTP (one pair from a Cat5e cable, using optional KA-HDBAL passive balun pair). HD-TVI HD BNC main output CVBS analog service video output on rear – Use standard hand held test monitors – Convenient aim and focus; ease of service 1/2.8” Sony progressive scan CMOS sensor with .07 lux native light sensitivity Flexible choice of Megapixel lens focal length to capture the desired field of view Supports both manual or DC iris lenses True Day/Night low light operation plus Digital Slow Shutter low light enhancement (More than 2~4X DSS should be limited to select applications.) Simple and easy to use OSD setup menu – Local 5-button menu control on rear cover – Up-the-cable control from OMNI EZHD recorders (or other compatible Coaxitron® control equipment) – Digital Wide Dynamic Range to handle the most challenging of bright or unbalanced lighting conditions – Programmable Back Light Compensation (BLC) and High Light Compensation (HLC) – Adjustable 3D Noise Reduction to increase low light picture clarity and conserve DVR HDD disk space – Privacy masking for 8 configurable zones – Lens shading compensation for even exposure out to the lens periphery – Defog improves image contrast in the presence of haze or smoke that obscures image details – Image H/V flip and rotate, digital zoom and more Dual voltage 24VAC/12VDC operation with low current draw Choice of black or silver housing (2 models) to blend or contrast with the décor Standard ¼-20 attachment points top and bottom for mounting flexibility in our out of a an optional protective housing HD-TVI cameras require HD-TVI compatible DVR systems Imaging Device 1/2.8” Sony 2.1Mp Progressive Scan CMOS Video Format Main Output : 1080p30/25, 720p/30/25 HD-TVI (OSD selectable) Secondary Output : CVBS (OSD selectable NTSC/PAL) service video test point Actual/Effective Picture Elements 2000 (H) x 1121 (V) / 1984 (H) x 1105 (V) Maximum Video Output Resolution 1920 (H) x 1080 (V) / 1080p @ 30/25 Sensitivity .1 lux color, .07 lux B/W (F=1.0) Day/Night Type Digital Day/Night Lens Type CS Type [C-mount with included adapter] DC iris support Video Output Connector Type TVI and CVBS : BNC 75Ω Sync. Mode Internal OSD Menu Multiple functions using 5 button controls on rear of housing; UTC Control OSD Languages English, Spanish, Portuguese, German, Russian, Japanese, French UTC Control Full OSD Menu access via up-the-cable (Coaxitron® type ) signaling DWDR / BLC / HLC OFF/WDR/BLC/HLC Selectable Adjustable for Level 1~10; also BLC area, HLC color. Auto Gain Control OFF; 2~42dB Electronic Shutter Auto; FLK; or Manual 1/30 (25) to 1/30,000 White Balance Auto / Push Lock / Auto EXT / Manual Color Correction Gamma 0.45~.65, adjustable Day & Night True D/N with motorized IR cut filter Optional color-only and B/W only modes under OSD control Digital Slow Shutter (DSS) DSS low light boost Off/Auto 2X~16X* *DSS levels above 4X should be used only after careful consideration of scene dynamics 3D-DNR Off/Low/Mid/High Digital Zoom 1X~8X Defog Off/Low/Mid/High Mirror Off / H-flip, V-flip, HV flip (rotate) Motion Detection Off/On for programmable zone with sensitivity adjust (pixel change detection) Privacy Mask Off/On with full programmability for 8 selectable zones Lens Shading Compensation Off/Low/Mid/High DPC (Defective Pixel Correction) Off/On Other OSD Functions Camera Title with position; Image Sharpness Power Source 12VDC/24VAC Power Consumption 12VDC:240mA / 24VAC:3.4W max. Operating Temperature 14°F~122°F ; -10°C~50°C Storage Temperature -4°F~140°F ; -20°C~60°C Humidity Less than 80% non-condensing Dimensions 2.28” x 2.28” x 4.77” / 58mm x 58mm x 121.4mm (includes BNC at rear) Weight 0.485 lb / 220g Certifications CE / FCC Warranty 3 years We welcome ALL Wholesale orders: Please contact us for special discounts on quantity / bulk orders. We also have special price for resellers and installers !! For any questions or inquiries, please contact ebay ID: esscctv Shipping Terms Item normally gets shipped out within 24 hours. Item will be normally shipped via UPS Ground, but we reserve the right to ship smaller items with USPS (either by First Class Mail or Priority Mail). All UPS shipments require a physical address International shipping is available. Please note all of our analog cameras are in NTSC format If provided, FREE shipping applies to continental US states only. ESS CCTV is not responsible for all customs, taxes, and duties occuring on international orders Warranty and Returns Most of the ESS CCTV items are covered by 1 year manufacturer warranty. The warrany only covers failure due to defects in material and workmanship by the manufacturer. The warranty does not cover damage due to everyday usage You may return merchandise purchased from ESS CCTV for a refund or a replacement. All product returns requires a RMA (return merchandise authorization) number. The RMA number should be written on your returning pacakge. Please contact us to issue your RMA number All returned items for a refund/credit should be in its original, “resalable” condition. You may not be responsible for a refund or credit otherwise. ESS CCTV follows ebay’s 14 days return policy. Items should be returned within 14 days from the order date to receive a refund. Items should be returned within 30 days from the received date for an exchange, replacement, or a store credit. Buyers are responsible for the shipping cost on all returns except for DOA (dead on arrival) products. 15% restocking fee is applied to any non-defective returns for a refund. . If your package is damaged upon arrival, please refuse the the delivery and contact us immediately. All shipping-related claims should be made within 3 calendar days after the date of receipt. Accessories and Expendables will not be covered under the warranty nor accepted for exchange or returns Contact us ebay ID: esscctv Monday to Friday 10:00 AM ~ 5:00 PM PST
