HD-SDI 2 MP Megapixel Security Dome Camera 1080p HD 25 IR LED SONY CMOS 4.3mm
HD-SDI 2 MP Megapixel Security Dome Camera 1080p HD 25 IR LED SONY CMOS 4.3mm
UH E202R HD-SDI Outdoor Turret Dome IR camera 2 Megapixel Full HD 1080p image, 4.3mm Fixed Lens, 25 IR LED 1/3" Sony CMOS 4.3mm Mega Pixel IR Fixed lens HD-SDI (1080p, 720p) / high resolution (1000 TV line over) HD-SDI (High Definition Serial Digital Interface) 0 lux at IR On (IR LED 25pcs) Upgraded water-resistant IP-67 housing 25 Smart IR LED with True Day & Night - ICR DNR (Digital Noise Reduction) Easy installation 12V DC HD-SDI cameras are recommended to use only with RG59/RG6 cables with crimp/compressed connectors What is the benefit of HD-SDI cameras? HD-SDI stands for High-Definition Serial Digital Interface. HD camera delivers a megapixel quality video without requiring IT network bandwidth, dropping packets, or reduced resolution from compression. HD camera provides superior surveillance environment compared to conventional VGA camera. HD cameras are easy to work with, and installers can migrate from analog cameras without any additional training. Actual Image Recorded Digital Zoom on above image 1 Digital Zoom on above image 2 Resolution HD-SDI(1080p, 720p) / 1000 TV line over Sensor 1/3" Sony CMOS Total Pixels 2010(H) × 1108(V) = 2.2M Pixel Effective Pixels 1944(H) × 1092(V) = 2.1M Pixel Scanning System Progressive S/N (Y signal) More than 52 dB (AGC Off) Video Output SMPTE292M (HD-SDI) Min.Illumination 0 lux at IR On White Balance Auto Electronic Shutter Speed Auto (1/30sec ~ 1/60,000sec) Brightness Adjustable (0 ~ 20 Step) DNR Middle Day & Night Extern Language English Operating Temperature / Humidity 14°F~122°F (-10°C~+50°C) / 30%~80% RH Storage Temperature / Humidity -4°F~+140°F (-20°C~+60°C) / 20%~90% RH Power DC 12V Only Signal Transmission 300 ~ 450ft (100 ~ 150m)(Max transmission range is depends on the cable manufacturer and the installation environment.) We welcome ALL Wholesale orders: Please contact us for special discounts on quantity / bulk orders. We also have special price for resellers and installers !! For any questions or inquiries, please contact ebay ID: esscctv Shipping Terms Item normally gets shipped out within 24 hours. Item will be normally shipped via UPS Ground, but we reserve the right to ship smaller items with USPS (either by First Class Mail or Priority Mail). All UPS shipments require a physical address International shipping is available. Please note all of our analog cameras are NTSC format If provided, FREE shipping applies to continental US states only. ESS CCTV is not responsible for all customs, taxes, and duties occuring on international orders Warranty and Returns Most of the ESS CCTV items are covered by 1 year manufacturer warranty. The warrany only covers failure due to defects in material and workmanship by the manufacturer. The warranty does not cover damage due to everyday usage You may return merchandise purchased from ESS CCTV for a refund or a replacement.All product returns requires a RMA (return merchandise authorization) number. The RMA number should be written on your returning pacakge.Please contact us to issue your RMA number All returned items for a refund/credit should be in its original, "resalable" condition. You may not be responsible for a refund or credit otherwise. ESS CCTV follows ebay's 14 days return policy. Items should be returned within 14 days from the order date to receive a refund. Items should be returned within 30 days from the received date for an exchange, replacement, or a store credit. Buyers are responsible for the shipping cost on all returns except for DOA (dead on arrival) products. 15% restocking fee is applied to any non-defective returns for a refund. . If your package is damaged upon arrival, please refuse the the delivery and contact us immediately. All shipping-related claims should be made within 3 calendar days after the date of receipt. Accessories and Expendables will not be covered under the warranty nor accepted for exchange or returns Contact us ebay ID: esscctv Monday to Friday 10:00 AM ~ 5:00 PM PST 2140 W Olympic Blvd. Ste 222, Los Angeles, CA 90006 213-500-7736
Specifications
| Restocking Fee | 15% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Type | Dome |
| Connectivity | Wired |
| Color Mode | Color Day, B&W Night |
| MPN | UH E202R |
| Brand | Sony |
| Model | UH E202R |
| Image Color | Both |
| Lens | 4.3mm Megapixel Lens |
| Indoor/Outdoor | Outdoor |
UH E202R HD-SDI Outdoor Turret Dome IR camera 2 Megapixel Full HD 1080p image, 4.3mm Fixed Lens, 25 IR LED 1/3″ Sony CMOS 4.3mm Mega Pixel IR Fixed lens HD-SDI (1080p, 720p) / high resolution (1000 TV line over) HD-SDI (High Definition Serial Digital Interface) 0 lux at IR On (IR LED 25pcs) Upgraded water-resistant IP-67 housing 25 Smart IR LED with True Day & Night – ICR DNR (Digital Noise Reduction) Easy installation 12V DC HD-SDI cameras are recommended to use only with RG59/RG6 cables with crimp/compressed connectors What is the benefit of HD-SDI cameras? HD-SDI stands for High-Definition Serial Digital Interface. HD camera delivers a megapixel quality video without requiring IT network bandwidth, dropping packets, or reduced resolution from compression. HD camera provides superior surveillance environment compared to conventional VGA camera. HD cameras are easy to work with, and installers can migrate from analog cameras without any additional training. Actual Image Recorded Digital Zoom on above image 1 Digital Zoom on above image 2 Resolution HD-SDI(1080p, 720p) / 1000 TV line over Sensor 1/3″ Sony CMOS Total Pixels 2010(H) × 1108(V) = 2.2M Pixel Effective Pixels 1944(H) × 1092(V) = 2.1M Pixel Scanning System Progressive S/N (Y signal) More than 52 dB (AGC Off) Video Output SMPTE292M (HD-SDI) Min.Illumination 0 lux at IR On White Balance Auto Electronic Shutter Speed Auto (1/30sec ~ 1/60,000sec) Brightness Adjustable (0 ~ 20 Step) DNR Middle Day & Night Extern Language English Operating Temperature / Humidity 14°F~122°F (-10°C~+50°C) / 30%~80% RH Storage Temperature / Humidity -4°F~+140°F (-20°C~+60°C) / 20%~90% RH Power DC 12V Only Signal Transmission 300 ~ 450ft (100 ~ 150m)(Max transmission range is depends on the cable manufacturer and the installation environment.) We welcome ALL Wholesale orders: Please contact us for special discounts on quantity / bulk orders. We also have special price for resellers and installers !! For any questions or inquiries, please contact ebay ID: esscctv Shipping Terms Item normally gets shipped out within 24 hours. Item will be normally shipped via UPS Ground, but we reserve the right to ship smaller items with USPS (either by First Class Mail or Priority Mail). All UPS shipments require a physical address International shipping is available. Please note all of our analog cameras are NTSC format If provided, FREE shipping applies to continental US states only. ESS CCTV is not responsible for all customs, taxes, and duties occuring on international orders Warranty and Returns Most of the ESS CCTV items are covered by 1 year manufacturer warranty. The warrany only covers failure due to defects in material and workmanship by the manufacturer. The warranty does not cover damage due to everyday usage You may return merchandise purchased from ESS CCTV for a refund or a replacement.All product returns requires a RMA (return merchandise authorization) number. The RMA number should be written on your returning pacakge.Please contact us to issue your RMA number All returned items for a refund/credit should be in its original, “resalable” condition. You may not be responsible for a refund or credit otherwise. ESS CCTV follows ebay’s 14 days return policy. Items should be returned within 14 days from the order date to receive a refund. Items should be returned within 30 days from the received date for an exchange, replacement, or a store credit. Buyers are responsible for the shipping cost on all returns except for DOA (dead on arrival) products. 15% restocking fee is applied to any non-defective returns for a refund. . If your package is damaged upon arrival, please refuse the the delivery and contact us immediately. All shipping-related claims should be made within 3 calendar days after the date of receipt. Accessories and Expendables will not be covered under the warranty nor accepted for exchange or returns Contact us ebay ID: esscctv Monday to Friday 10:00 AM ~ 5:00 PM PST 2140 W Olympic Blvd. Ste 222, Los Angeles, CA 90006 213-500-7736
