HD CCTV 4MP IP Camera Module Full Network Security IPC board H.265 ONVIF +lens
HD CCTV 4MP IP Camera Module Full Network Security IPC board H.265 ONVIF +lens
1/2.9" FH8852+GC4053 4MP CMOS IP Camera ModuleUltra-low night vision illumination,Support IR LED / White Light Led / Warm Yellow Light,H.265 Support dual stream, Max 2560*1440,Support full network&ONVIF protocol,Support DWDR, IR-CUT,Support corridor mode,Single layer 38mm*38mm board.Lens: 3.6mm Lens, Optional: 2.8mm/3.6mm/4mm/6mm/8mm/12mm/16mm (If you need to choose the lens, please note) Specifications:Chipest 1/2.9" FH8852 + GC4053 Illumination Color 0.01Lux/F1.2; B&W 0.001Lux/F1.2 SNR ≥50db(AGC OFF) WDR DWDR: ＞80db Audio Input / Audio Output1CH MIC Input/linear input / 1CH Audio InputIO Function 1CH Reset,1CH Alarm input,1CH Alarm output Coding Format H.265 Main Stream 2560*1440,1-30 FPS/S 2304*1296,1920*1080,1280*720,1-30 FPS/S Sub stream 704*576,640*480,640*360,352*288,1-30 FPS/S Video-coding Compression 128Kbps-3072bps continuous adjustable Subtitle Overlay Support channel name,Date,Four position of character stack is adjustable Data Record Video, Picture Storage Method Circular Recording, Alarm Recording Alarm Transfer Browser, Management Software, IO Output Support Protocol Default ONVIF 2.6&Full network protocol PC Browser Mobile App Support IE6.0 and above browser Support IOS,Android Temperature / Humidity-20℃- +60℃ /0% - 90%Power supplyDC12V / POEConsumption1.5W删除列删除行插入列插入行向右合并单元格向下合并单元格水平拆分单元格垂直拆分单元格背景色删除表格全选表格隐藏边框 Packaging included:1x HD 4MP CCTV IP Camera Module1x cctv microphone1x HD 3.6mm lens 1x IR Cut 1x Module Video Power Cable Warranty Term: One Year WarrantyPayment:1. If you need to buy more goods, but the price is not cheap enough, or you did not find them in our store, please contact us!2. Buyers response for all tax or VAT under any circumstances. Shipping: 1. The item will be shipped within 1-3 business days after payment.2. All products have been checked and packaged in good condition before dispatch. 3. The package will be shipped by SpeedPAK or China post, if you need express shipping, please send ebay message to us to check the express shipping cost. If your order is large enough, we will ship it by DHL, Fedex, UPS or E-EMS.4. We provide 12 months Warranty, if the item is defective, please notify us within 5 days of delivery. We provide replacement service for defective items. Feedback:1. We will do a positive feedback automatically after receiving your positive feedback. We would appreciate your positive feedback. 2. If you are not satisfied with our product or service, please contact us with your problem before leaving a negative/neutral feedback or open a dispute, we work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you and always leave positive feedback to all our customers.We care about our valued customers, and will always be willing to help you. So if you have any problems, please let me know immediately.
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Model | ONVIF H. 265 |
| Country/Region Of Manufacture | China |
| Color Mode | Color |
| Surveillance Technology | CCTV |
| Connectivity | IP/Network - Wired |
| Type | IP board |
| Features | Audio Recording |
| Brand | Unbranded/Generic |
1/2.9″ FH8852+GC4053 4MP CMOS IP Camera ModuleUltra-low night vision illumination,Support IR LED / White Light Led / Warm Yellow Light,H.265 Support dual stream, Max 2560*1440,Support full network&ONVIF protocol,Support DWDR, IR-CUT,Support corridor mode,Single layer 38mm*38mm board.Lens: 3.6mm Lens, Optional: 2.8mm/3.6mm/4mm/6mm/8mm/12mm/16mm (If you need to choose the lens, please note) Specifications:Chipest 1/2.9″ FH8852 + GC4053 Illumination Color 0.01Lux/F1.2; B&W 0.001Lux/F1.2 SNR ≥50db(AGC OFF) WDR DWDR: ＞80db Audio Input / Audio Output1CH MIC Input/linear input / 1CH Audio InputIO Function 1CH Reset,1CH Alarm input,1CH Alarm output Coding Format H.265 Main Stream 2560*1440,1-30 FPS/S 2304*1296,1920*1080,1280*720,1-30 FPS/S Sub stream 704*576,640*480,640*360,352*288,1-30 FPS/S Video-coding Compression 128Kbps-3072bps continuous adjustable Subtitle Overlay Support channel name,Date,Four position of character stack is adjustable Data Record Video, Picture Storage Method Circular Recording, Alarm Recording Alarm Transfer Browser, Management Software, IO Output Support Protocol Default ONVIF 2.6&Full network protocol PC Browser Mobile App Support IE6.0 and above browser Support IOS,Android Temperature / Humidity-20℃- +60℃ /0% – 90%Power supplyDC12V / POEConsumption1.5W删除列删除行插入列插入行向右合并单元格向下合并单元格水平拆分单元格垂直拆分单元格背景色删除表格全选表格隐藏边框 Packaging included:1x HD 4MP CCTV IP Camera Module1x cctv microphone1x HD 3.6mm lens 1x IR Cut 1x Module Video Power Cable Warranty Term: One Year WarrantyPayment:1. If you need to buy more goods, but the price is not cheap enough, or you did not find them in our store, please contact us!2. Buyers response for all tax or VAT under any circumstances. Shipping: 1. The item will be shipped within 1-3 business days after payment.2. All products have been checked and packaged in good condition before dispatch. 3. The package will be shipped by SpeedPAK or China post, if you need express shipping, please send ebay message to us to check the express shipping cost. If your order is large enough, we will ship it by DHL, Fedex, UPS or E-EMS.4. We provide 12 months Warranty, if the item is defective, please notify us within 5 days of delivery. We provide replacement service for defective items. Feedback:1. We will do a positive feedback automatically after receiving your positive feedback. We would appreciate your positive feedback. 2. If you are not satisfied with our product or service, please contact us with your problem before leaving a negative/neutral feedback or open a dispute, we work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you and always leave positive feedback to all our customers.We care about our valued customers, and will always be willing to help you. So if you have any problems, please let me know immediately.
