1X 700TVL Effio-E DSP 1/3″ SONY CCD Board Camera 3.7mm Pinhole Lens DC12V
1X 700TVL Effio-E DSP 1/3" SONY CCD Board Camera 3.7mm Pinhole Lens DC12V
Mini HD SONY Effio-E 700TVL DSP CCD PCB Board Hidden CCTV Camera with 3.7mm Board Lens *****THIS IS NTSC VERSION**** Overview: 1/3" Sony CCD 700TV Lines, 0.01Lux Lens: 3.7mm pinhole lensSize:32*32mm BNC Connector Cable Power: 12 V DC (Power adapter Not Included) NTSCMini Module CCD Camera Specification: CXD Series Model Name Sony CCD Module Camera With 3.7mm Pinhole Lens Camera Image Sensor 1/3"Sony Super HAD CCD DSP Sony Effio-E (4140+811) Resolution 700TVL Min. Illumination 0.01Lux Effective Pixels NTSC: 976(H)x494(V) Video Signal NTSC Standard Lens 3.7mm Pinhole Lens Elec Shutter 1/50(1/60)s to 1/100,000s Day& Night Electronic Day& Night White Balance Auto Synchronization Internal Synchronization Video Output 1.0Vp-p Composite Output (75Ω/BNC) S/N Ratio More than 48dB BLC Auto AGC Auto Industrial Power Supply 12 V DC ± 10% Standard Working Temp -20 °C - 60 °C (14 °F-140 °F), Humidity 90% or less (non-condensing) Output BNC Connector Dimension 32(W)*32(L)mm Weight 38g Packing List: BNC Cable x 1 700tvl Camera x 1
Specifications
| Restocking Fee | 20% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Model | Camera Board |
| Maximum Resolution | 700TVL |
| Color Mode | Color Day, B&W Night |
| Location | Indoor Only |
| Surveillance Technology | Analog |
| Type | Box/Body |
| Features | Wide Angle |
| MPN | Does Not Apply |
| Power | 12VDC |
| Brand | Unbranded/Generic |
| Voltage | 12 V |
Mini HD SONY Effio-E 700TVL DSP CCD PCB Board Hidden CCTV Camera with 3.7mm Board Lens *****THIS IS NTSC VERSION**** Overview: 1/3″ Sony CCD 700TV Lines, 0.01Lux Lens: 3.7mm pinhole lensSize:32*32mm BNC Connector Cable Power: 12 V DC (Power adapter Not Included) NTSCMini Module CCD Camera Specification: CXD Series Model Name Sony CCD Module Camera With 3.7mm Pinhole Lens Camera Image Sensor 1/3″Sony Super HAD CCD DSP Sony Effio-E (4140+811) Resolution 700TVL Min. Illumination 0.01Lux Effective Pixels NTSC: 976(H)x494(V) Video Signal NTSC Standard Lens 3.7mm Pinhole Lens Elec Shutter 1/50(1/60)s to 1/100,000s Day& Night Electronic Day& Night White Balance Auto Synchronization Internal Synchronization Video Output 1.0Vp-p Composite Output (75Ω/BNC) S/N Ratio More than 48dB BLC Auto AGC Auto Industrial Power Supply 12 V DC ± 10% Standard Working Temp -20 °C – 60 °C (14 °F-140 °F), Humidity 90% or less (non-condensing) Output BNC Connector Dimension 32(W)*32(L)mm Weight 38g Packing List: BNC Cable x 1 700tvl Camera x 1
