UBIQUITI POE-24-24W-G (Hi-Power) OUTPUT
UBIQUITI POE-24-24W-G (Hi-Power) OUTPUT
POE-24-24W-G (Hi-Power)Dimensions88 x 57 x 33 mm (3.47 x 2.24 x 1.30")Weight158.5 g (5.59 oz)Output Voltage24VDC @ 1.0ALAN Activity IndicatorNoGigabit LAN PortYesRemote Reset CapabilityYesReset ButtonYesRated Voltage100-240VAC @ 50/60HzInput Current0.6A @ 120VAC, 0.4A @ 240VACInrush Current<60A Peak @ 120VAC, <120A Peak @ 230VACEfficiency80+%Output Ripple1% Max.Switching Frequency65 kHzLine Regulation≤ 3%Load Regulation≤ 5%2-Pair PoweringPins 4, 5 (+) and Pins 7, 8 (-)4-Pair Powering-Operating Temperature0 to 40° C (32 to 104° F)Storage Temperature-30 to 70°C (-22 to 158° F)Operating Humidity35 to 95% NoncondensingAC ConnectorIEC-320 C6Data IN / PoERJ45 Shielded SocketSurge ProtectionDifference and Common ModeClamping Protection11V Data, 60V PowerMax. Surge Discharge1500A (8/20 μs) PowerPeak Pulse Current36A (10/1000 μs) DataShunt Capacitance<5 pF dataResponse Time<1 nsCertificationsCE, FCC, IC, UL
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | Ubiquiti Networks |
| Type | DC Power Connector |
| Model | POE-24-24W-G |
| Connectivity | Wired |
| Features | Wi-Fi |
POE-24-24W-G (Hi-Power)Dimensions88 x 57 x 33 mm (3.47 x 2.24 x 1.30″)Weight158.5 g (5.59 oz)Output Voltage24VDC @ 1.0ALAN Activity IndicatorNoGigabit LAN PortYesRemote Reset CapabilityYesReset ButtonYesRated Voltage100-240VAC @ 50/60HzInput Current0.6A @ 120VAC, 0.4A @ 240VACInrush Current<60A Peak @ 120VAC, <120A Peak @ 230VACEfficiency80+%Output Ripple1% Max.Switching Frequency65 kHzLine Regulation≤ 3%Load Regulation≤ 5%2-Pair PoweringPins 4, 5 (+) and Pins 7, 8 (-)4-Pair Powering-Operating Temperature0 to 40° C (32 to 104° F)Storage Temperature-30 to 70°C (-22 to 158° F)Operating Humidity35 to 95% NoncondensingAC ConnectorIEC-320 C6Data IN / PoERJ45 Shielded SocketSurge ProtectionDifference and Common ModeClamping Protection11V Data, 60V PowerMax. Surge Discharge1500A (8/20 μs) PowerPeak Pulse Current36A (10/1000 μs) DataShunt Capacitance<5 pF dataResponse Time<1 nsCertificationsCE, FCC, IC, UL
