ELP H.264 USB Camera module w/ no distortion lens 110degree Low Light 2MP Webcam
ELP H.264 USB Camera module w/ no distortion lens 110degree Low Light 2MP Webcam
HomePaymentShippingReturn PolicyAbout UsContact UsFeedbackELP 1080P Webcam with 110degree no distortion lens USB2.0 SONY IMX322 LOW ILLUMINATION H.264 Web Camera Module Color CMOS Sensor USB Camera for Android Linux Windows Key Features:1. Ultra Low light Camera, Minimum illumination 0.01lux2. Support OTG protocal3. High quality digital MIC, support single, dual channel4. Max resolution :1920*1080P ,2.0 Megapixel5. Highly advanced Sony IMX322 Sensor6. Compression format : H264 /MJPEG / YUV2(YUYV)7. White balance Function: Resolve color reduction and tone processing issues8. Lens: 110 degree no distortion lens Specifications: ModelELP-USBFHD06H-H110SensorSony IMX322Lens Size1/2.9 inchPixel Size12.8X11.6 mmimage area2000(H)X1121(V) approx. 2.24 M pixelsMax. Resolution1080PCompression formatH264 /MJPEG / YUV2（YUYV）Resolution & frameH264: 320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fpsMJPEG:320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fpsYUV:320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 15 fpsS/N Ratio42dBDynamic Range86dBSensitivity5.0V/lux-sec@550nmMini illumination0. 01 luxShutter TypeElectronic rolling shutter / Frame exposureConnecting Port typeUSB2.0 High SpeedFree Drive ProtocolUSB Video Class（UVC）Support OTG ProtocolUSB2.0 OTGAECSupportAEBSupportAGCSupportAdjustable parametersBrightness, Contrast, Saturation, Hue, Sharpness, Gamma,Gain, White balance, Backlight Contrast, ExposureLens ParameterStandard 3.6mm, optional 2.1/2.5/2.8/6mm/FOV(D)170 Degree/FOV(D)180 DegreeDigital audioHigh quality digital MIC, support single, dual channelLED board power connectorSupport 2P-2.0mm socketPower supplyUSB BUS POWER 4P-2.0mm socketPower supplyDC5VOperating Voltage140mA~190mAWorking current-10～70℃Working temperature-20～85℃Board size /Weight38X38mm（Compatible 32X32mm）/ about 30gCableStandard 1M / optional 2M,3M,5MOperating system requestWin7 Win8Linux 2.6 or aboveAndroid 4.0 or above Applications:used for all kinds of machine as below:machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display, automaticvending machine, safety box, notebook, video door phone, MID, Tablet external, evaluator, Medical Equipment, on-the-spot lawenforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system,automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed videoshooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance, endoscope, Medical auxiliary equipment, etc. PaymentDelivery detailsTerms of salesAbout usContact usPayment1.We accept Paypal only. 2.Payment must be received within 7 working days. Or unpaid case will be opened automatically. Delivery details1.We ship goods to customer's confirmed paypal address. Please be sure your paypal address is correct before bidding. 2.Items will be shipped out within 48 hours once payment cleared. By registered air mail with tracking number. Orders placed on weekends or holidays will be processed on Monday or next working day. 3.International buyers please note: Import duties,taxes and charges are not included in the item price or shipping charges. These fees are buyers responsibility. So, Please check with your country's customs office to determine what these additional costs will be prior to bidding. 4.Delivery time:For USA buyers we'll ship by e-packet takes arround 7-12 working days. Other countries we'll ship by Registered Air Mail. Arround delivery time as bellow for your referrence.Australia, Canada 10-18 working daysUK, France, Austria, Germany, Spain and other Europe countries: 10-25 working daysGreece, Malta 15-40 working daysRussian Federation, Italy, Brazil, Africa countries: 20-40 days due to customs restrictionThe estimated arrival time above just for your refference, Not guaranteed. We don't responsible for any customs duties. Terms of sales1.If the goods dead on arrival, Please take photoes for us confirmation and reach us first time for exchange or refund. 2.Buyers have purchased a wrong item or don't like the item received, Please return within 7 days and reach us first before returning. 3.Ailipu Technology Co., Ltd warrants our product to be free from manufacturers maintenance for 2 years. The warranty will not be covered under the following conditions : a) Out-of-warranty products. b) The product is modified without Ailipu Technology Co.,Ltd approval. c) Obvious attack of appearance whatever it is. d) The product is subjected to unusual physical or electrical stress, including physical damage, burnt components and broken connectors.4. The customer is responsible for returning the defective product at his own expense. About usAilipu Technology Co.,Ltd have 10 years history, is a professional manufacturer of surveillance system. We produce traditional analog CCTV camera, standalone DVR recorder for cctv camera,but also produce popular megapixel network IP cameras, NVR recorder for IP cameras too.Besides, Ailipu Technology Co., Ltd already developing its own special USB Cameras for industrial vision. Recently, Ailipu company present new USB cameras module range from 30W Pixel, 1megapixel, 2megapixe, 3megapixel, 5 megapixel to 5megapixel autofocus, which already used in all kinds of industrial system. We can also OEM or customize products specially by customers' requirements.Contact usIf you have any questions,Please contact with us via eBay message! Our Service Officer will reply in 24 hours!(Excluding Weekends and Public Holidays) Working time:Our Duty TimeChina TimeUSA (pacific time) StartEndStartEndMondayAM 9:00PM 18:00SundayPM 17:00AM 2:00TuesdayAM 9:00PM 18:00MondayPM 17:00AM 2:00WednesdayAM 9:00PM 18:00TuesdayPM 17:00AM 2:00ThursdayAM 9:00PM 18:00WednesdayPM 17:00AM 2:00FridayAM 9:00PM 18:00ThursdayPM 17:00AM 2:00SaturdayOut of DutyFriday SaturdaySundayOut of DutySaturday Sunday During the duty time ,we can give you a quick respond. If we are out of work ,please kindly be patient and considerable to give us a little more time ,not just leave the neutral or negative feedback without communication ,thank you for your cooperation !
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | ELP |
| MPN | Does Not Apply |
| Model | ELP-USBFHD06H-H110 |
| Country/Region Of Manufacture | China |
| Connectivity | USB |
| Minimum Illumination(Lux) | 0.01Lux |
| Is Customized | Yes |
| High Definition | 1080P(Full-HD) |
| Dimensions (L X W X D)(mm) | 32*32/38*38mm |
| Audio Output | with mic on board |
| Dynamic Range | 86dB |
| UPC | Does not apply |
| Features | Low light |
| Smart Home Protocol | Thread |
| Surveillance Technology | CCTV |
| Smart Home Compatibility | Low light Webcamera |
| Compatible Brand | USB2.0 camera |
| Location | Indoor Only |
| Maximum Resolution | 1920x1080 |
| Storage Capacity | HD Camera |
| Power | DC5V |
| Operating Sound Rating | Webcam |
