ELP Fisheye Lens 4K 30fps Mini Webcam MJPEG Wide Angle Ultra HD USB Camera
ELP Fisheye Lens 4K 30fps Mini Webcam MJPEG Wide Angle Ultra HD USB Camera
ELP 3840x2160 Webcameras with 170degree Fisheye Lens High Resolution Mjpeg 30fps Full HD Webcam,Sony IMX415 Sensor 4K USB Camera for Android, Linux, Windows Features:1) 4K Webcam High resolution , Max resolution 3840x21602) Advanced Sony (1/2.8'' ) IMX415 image sensor3) Support OS: WindowsAndroidLinux , support raspberry piMac4) Compression : MJPEG&YUY2 Specification :Model NO.:ELP-USB4K03-BL170Image SensorSONY IMX415 (1/2.8” )Max. Resolution3840(H) *2160 (V)Sensitivity1000mV/Lux-secPixel Size1.45µmx1.45µmCompression formatMJPEG / YUY2（YUYV）Resolution & frame3840x2160@ 30fps MJPEG / 2592x1944@ 30fps MJPEG2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG1920x1080@ 30fps MJPEG/ 1280x960@30fps MJPE1280x720@ 30fps MJPEG / 800 x 600@ 30fps MJPEG640x480@ 30fps MJPEG / 320x240@ 30fps MJPEG3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY22048x1536@ 3fps YUY2 /1600x1200@ 5fps YUY21920x1080@ 5fps YUY2/1280x960@5fps YUY21280x720@ 5fps YUY2 / 800 x 600@ 20fps YUY2640x480@ 30fps YUY2 / 320x240@ 30fps YUY2Center definition1000LW/PH (Center)S/N Ratio30dBSensitivity0.65V/lux-sec@550nmMinimum illumination0.2luxShutter TypeElectronic rolling shutter / Frame exposureConnecting Port typeUSB2.0 High SpeedAECSupportAEBSupportAGCSupportFocusing methodfixed focusAdjustable parametersBrightness, Contrast, Hue, Saturation, Sharpness, Gamma, WhiteBalance, ExposureLens Parameter with 170degree fisheye lens Power supply& connectorUSB BUS POWER 4P-2.0mm socketPower VoltageDC5VPower Current200mABoard Size38mm × 38mmStorage Temperature-20°C to 70°CWork Temperature0°C to 60°CUSB Cable3M(1M/2M/5M optional)Operating System supportWin XP/Vista/Win7/Win8 / Win10Linux with UVC（above linux-2.6.26） Application :Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site monitoring, environmental monitoring, etc.used for all kinds of machine as below:machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external, evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system, automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance, endoscope, Medical auxiliary equipment, etc.
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Compatible Brand | Webcamera with usb2.0 |
| Power Source | USB |
| MPN | Does Not Apply |
| Smart Home Compatibility | usb camera |
| High Definition | 8.0 Megapixels |
| Brand | ELP |
| Herstellernummer | 4K USB Kamera |
| Type | 4K usb camera |
| Maximum Resolution | 3840x2160 |
| Model | ELP-USB4K03-BL170 |
| Connectivity | usb2.0 |
| Features | manual focus |
| Storage Capacity | Webcam |
| Smart Home Protocol | high difination |
| Operating Sound Rating | digital camera |
| Power | DC5V |
| Surveillance Technology | CCTV |
| Location | Indoor Only |
ELP 3840×2160 Webcameras with 170degree Fisheye Lens High Resolution Mjpeg 30fps Full HD Webcam,Sony IMX415 Sensor 4K USB Camera for Android, Linux, Windows Features:1) 4K Webcam High resolution , Max resolution 3840×21602) Advanced Sony (1/2.8” ) IMX415 image sensor3) Support OS: WindowsAndroidLinux , support raspberry piMac4) Compression : MJPEG&YUY2 Specification :Model NO.:ELP-USB4K03-BL170Image SensorSONY IMX415 (1/2.8” )Max. Resolution3840(H) *2160 (V)Sensitivity1000mV/Lux-secPixel Size1.45µmx1.45µmCompression formatMJPEG / YUY2（YUYV）Resolution & frame3840x2160@ 30fps MJPEG / 2592×1944@ 30fps MJPEG2048x1536@ 30fps MJPEG /1600×1200@ 30fps MJPEG1920x1080@ 30fps MJPEG/ 1280×960@30fps MJPE1280x720@ 30fps MJPEG / 800 x 600@ 30fps MJPEG640x480@ 30fps MJPEG / 320×240@ 30fps MJPEG3840x2160@ 1fps YUY2 / 2592×1944@ 1fps YUY22048x1536@ 3fps YUY2 /1600×1200@ 5fps YUY21920x1080@ 5fps YUY2/1280×960@5fps YUY21280x720@ 5fps YUY2 / 800 x 600@ 20fps YUY2640x480@ 30fps YUY2 / 320×240@ 30fps YUY2Center definition1000LW/PH (Center)S/N Ratio30dBSensitivity0.65V/lux-sec@550nmMinimum illumination0.2luxShutter TypeElectronic rolling shutter / Frame exposureConnecting Port typeUSB2.0 High SpeedAECSupportAEBSupportAGCSupportFocusing methodfixed focusAdjustable parametersBrightness, Contrast, Hue, Saturation, Sharpness, Gamma, WhiteBalance, ExposureLens Parameter with 170degree fisheye lens Power supply& connectorUSB BUS POWER 4P-2.0mm socketPower VoltageDC5VPower Current200mABoard Size38mm × 38mmStorage Temperature-20°C to 70°CWork Temperature0°C to 60°CUSB Cable3M(1M/2M/5M optional)Operating System supportWin XP/Vista/Win7/Win8 / Win10Linux with UVC（above linux-2.6.26） Application :Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site monitoring, environmental monitoring, etc.used for all kinds of machine as below:machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external, evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system, automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance, endoscope, Medical auxiliary equipment, etc.
